AC Control: 750-10-0002

The AC Control 750-10-0002 sports a NEMA 4X die-cast aluminum case with hinged cover and a motor HP selection jumper. With input voltage options of 115 or 208/230 at 50/60 Hz, the ac motor control has both short circuit and undervoltage/overvoltage protection. It has 3-phase drive output. Contact one of our technical sales staff today to discuss which AC Motor and control package is the best solution for you.

Download Specs
Download Manual
AC Line Input Drive Output
Voltage (V) 50/60 Hz PHASE (O) Maximum Current (A) Fuse or circuit breaker rating (A) Voltage range (V) PHASE (O) Max. cont. load current (RMS A/0) Max. power Enclosure Type
HP KW
115 1 14.4 20 0-208/230 3 3.6 1 0.75 NEMA 4X
208/230 8.1 15





ac-motor-speed-control-outline-groschopp

field_58898b1ef9018 Motor HP selection jumper Speed regulation ±2 1/2% base speed
Slip compensation Inrush current limit Speed range: 60:1
Motor overload I²T Holding torque at zero speed Length: 9.53 in.
Short circuit protection Industrial duty die-cast aluminum case with hinged cover Width: 5.51 in.
Undervoltage/overvoltage protection Features: acceleration, deceleration, brake, inhibit Height: 5.86 in.
