OEM Design Checklist & Application Data Worksheet

August 24, 2011

Use this design checklist, along with the Ingress Protection (IP) and Temperature Class charts to gather data about your application. The speed vs. torque comparison graph is helpful in selecting the right motor type. All of the information is essential to refining the motor selection and customization process and achieving a maximized overall motor system solution.

When speaking with your sales representative it is important to have:

  • Information about your application
  • Information about the type of motor you are looking for

Use the print version as a tool to evaluate your application and identify which type of motor or gearmotor would best fit your application (download may take a moment).



OEM Design Checklist & Application Data Worksheet





How to use the Motor Search Tool

Narrow your search by selecting motor type, gearbox, voltage, and phase options for your desired motor.

Select a dominant variable: choose one of the three parameters to narrow your search. The selected variable determines which slider bar you will be able to manually move.

Use the slider corresponding to your dominant variable to further narrow your motor selection. The other sliders will automatically move to show available ranges based on the range of your selected variable.

Results will upload as your search criteria changes. If you have any questions regarding your results or how to use the search tool, you can chat with us using the green tab on the left-hand side of your screen.


Note: Groschopp Universal motors are custom built to fit your application so no additional options are available to narrow the search. Selecting the Universal motor type will prompt a message taking you to the Universal product page.
