Brushless Control: 750-30-0006

The BL Control 750-30-0006 is our low voltage,digital control option. This brushless speed control features a user-friendly front panel for RPM adjustment. With its microprocessor-based design, this control has non-volatile memory stores, a program-enable jumper, and a large 4-digit LED display. Contact one of our technical sales staff today to discuss which Brushless DC Motor and control package is the best solution for you.

Download Specs
Download Manual
Power Speed Control
Enclosure Type Supply Voltage (V) Motor Voltage (V) Current (A) Closed loop Speed pot. DC Signal Digital Control
Cont. Peak
NEMA 4X 12-48 VDC 12-48 VDC 8.0 12.0 x - - x

brushless-motor-control-outline

Microprocessor-based design Transient voltage protection Configure min/max speed
Digital closed-loop accuracy to ±1/2 RPM Jumper selection of drive output voltage Program-enable jumper
Self-contained power supply for motor halls Non-volatile memory stores Length: 4.63 in.
Factory or field programmable via front panel Large 4-digit 1/2" LED display Width: 3.62 in.
Configurable alarms/status and alarm indicators Forward/reverse control Height: 1.66 in.
Features: acceleration, deceleration, brake, inhibit
